T-Engine Appliance

TeamacaronNEW

Teamacaron




Features of Teamacaron

Macaron-shaped Minimal Computer for Ubiquitous Devices.

  • Teamacaron is the minimal computer for embedded control. By this computer, you can develop embedded devices in a short period of time, which balance embedded real-time control with advanced information processing.
  • In addition to the compact and high-performance RTOS "T-Kernel" and ARM11 Core CPU, Teamacaron includes lots of middleware such as "T-Kernel Extension" for process management and file management, "TCP/IP" for network functions, and "PMC T-Shell" for GUI functions. These middleware easily realize the functions of information OS at the same level as Windows or Linux.
  • Teamacaron Development Kit includes the integrated development environment "Eclipse for PMC T-Kernel". If this product and Windows PC are ready, you can start program development or debugging right away.
  • Taking advantage of small and slim 50-sq-mm semi-open package, it can be embedded in small end products.
  • Using I/O interfaces such as RGB output, LAN, USB, microSD and Serial(2ch), Teamacaron can be used for a device control. You can connect Teamacaron to PC peripherals(e.g. LCD monitor).

Photos

Tutorials

Reference

Brochure

Brochure Standard Price(Tax not included)
TeamacaronRoHS
pdficon[1.01MB]		 Teamacaron Development Kit
(Hardware + Software + Development Environment + Documents)		 98,000 yen Request for Quotation
Teamacaron Execution Kit
(Hardware + Software License)		 58,000 yen

Teaboard2/ARM920-MX1

Teaboard2/ARM920-MX1

What is Teaboard2/ARM920-MX1?

Teaboard2/ARM920-MX1 is the low-priced T-Engine appliance board. If you need the low-priced delivery board or the development environment for every engineer, Teaboard2/ARM920-MX1 is the best.

Teaboard2/ARM920-MX1 has a variety of functions. For example, Network functions such as LAN and TCP/IP, I/O functions such as USB, SD card(*) and JTAG I/F are already equipped.

Basic software, such as PMC T-Kernel, PMC T-Kernel Extension, and PMC T-Monitor, go along with Teaboard2/ARM920-MX1.

Therefore it is the best board to exercise development of software for T-Engine.
Also, it can be used as the low-priced delivery board.
Teaboard2/ARM920-MX1 is a RoHS Directive compliant product.

(*) Many SD and microSD cards are available on Teaboard2, but there are some exceptions.

Features and uses of Teaboard2/ARM920-MX1
  • Teaboard2/ARM920-MX1 is the same size as the standard T-Engine board. It helps smooth transplant of software from the board to the T-Engine development kits, which have wide variety of CPU.
  • The board is equipped with I/O, such as LAN, 7 segments LED and versatile switches, which are easily available for exercise of software development.
  • Texts and sample programs are also provided, so that even the beginners who have not programmed on T-Engine can start learning T-Engine software development easily.
  • Reduction in cost positively helps massive introduction of the boards in schools.
  • It can be available as a low-priced board computer for embedded and control use.

Photos

Tutorials

Brochure and Price

Brochure Standard Price(Tax not included)
Teaboard2/ARM920-MX1RoHS pdficon[285KB] 48,000 yen Request for Quotation
TeaPARTNER pdficon[144KB] 150,000 yen

Teatouch

Teatouch




Features of Teatouch
  • Teatouch is the low-priced board with LCD for embedded systems. The realtime OS "T-Kernel" runs on Teatouch. You can use Teatouch as the delivery board with touch panel function. In addition, we can give you a volume discount when you use a large quantity of Teatouch for mass production or education use.
  • Teatouch has a wide variety of I/O functions, such as LAN, USB(function), SD card, serial port, GPIO, etc.
    Teatouch includes basic software such as T-Kernel and T-Kernel Extension as well as middlewares including TCP/IP and Device drivers.
  • Teatouch is a RoHS Directive compliant product.
  • Teatouch includes GUI based integrated development environment "Eclipse for PMC T-Kernel", the development environment including GNU based compiler, and T-Kernel related library. You can start development or debugging the program instantly if you have got Teatouch and Windows PC.
  • The optional middleware set for Teatouch "PMC T-Shell/Teaboard" is also available. By using lots of GUI parts and visual language "MicroScript", you can make a rich GUI easily.
  • English versions of software and related documents are available in CD-ROM.

Photos

Brochure and Price

Brochure Standard Price(Tax not included)
TeatouchRoHS pdficon[1592KB] 78,000 yen Request for Quotation

μTeaboard/ARM7-AT91

μTeaboard/ARM7-AT91






Features and uses of μTeaboard/ARM7-AT91
  • μTeaboard/ARM7-AT91 is the low-priced T-Engine appliance board.
  • If you need the low-priced delivery board or the development environment for every engineer, μTeaboard/ARM7-AT91 is the best.
  • μTeaboard/ARM7-AT91 has a variety of functions. For example, Network functions such as LAN and TCP/IP, I/O functions such as GPIO and SERIAL PORT are already equipped.
  • Basic software, such as PMC T-Kernel, and PMC T-Monitor, go along with μTeaboard/ARM7-AT91.
  • μTeaboard/ARM7-AT91 is a RoHS Directive compliant product.

Photos

Brochure and Price

Brochure Standard Price(Tax not included)
μTeaboard/ARM7-AT91RoHS pdficon[220KB] 27,000 yen

T-Kernel/x86 Evaluation Kit

T-Kernel/x86 Development Kit

What is T-Kernel/x86 Evaluation Kit?

T-Kernel/x86 Evaluation Kit is the development package for x86 platform embedded system. T-Kernel/x86 can carry out on PC/AT compatible board or emulation software "VMware".

T-Kernel/x86 Evaluation Kit includes all the software for development of high-performance embedded products which have GUI, such as PMC T-Kernel/x86, middleware, driver and development environment.

Features of T-Kernel/x86 Evaluation Kit
  • By the T-Kernel based system, you can use extension boards and peripheral devices designed for PC/AT compatible machines.
  • If you use emulator software, you can advance development and debugging of the software without hardwares such as T-Engine boards.
  • You can use T-Kernel/x86 Evaluation Kit as teaching materials of Real-time OS and T-Kernel, because you can easily establish T-Kernel execution environment on Windows.
  • You can port the software on T-Kernel of other CPUs to PMC T-Kernel/x86 easily by recompiling the software. In addition, it is easy to por t the sof tware of PMC T-Kernel /x86 to T-Kernel of other CPUs.
  • T-Kernel/x86 Evaluation Kit includes "Ecl ipse f or PMC T-Kernel ", a GUI-based integrated development environment. By operating GUI, you can proceed a series of development such as coding, compi l ing and debugging. Besides, it is easy to learn.

Photos

Tutorials

Brochure and Price

Brochure Standard Price(Tax not included)
T-Kernel/x86 Evaluation Kit pdficon[608KB] 90,000 yen Request for Quotation

UC (Ubiquitous Communicator)NEW

UC

What is UC?

UC(Ubiquitous Communicator) is the portable information tool which can realize the efficient communications by person and object or person and place in a ubiquitous computing environment.

UC is equipped with ucode tag reader. Therefore UC can be used for a wide variety of applications such as e-commerce, traceability, autonomous transfer support, if you develop software using the attached software materials.

Features of UC
  • UC is the personal terminal for a ubiquitous computing age, equipped with RFID reader and the other advanced functions.
  • A lot of peripheral I/O functions including the built-in camera are available.
  • UC is one of the T-Engine appliances, which OS is T-Kernel. Software for UC are nearly compatible with software for T-Engine.
  • The GUI middleware package "PMC T-Shell" for UC is also available. Using PMC T-Shell, you can save time of developing programs which include a collaboration of UC, peripheral I/O and GUI functions.

Photos

Brochure

Brochure
UC pdficon[740KB]

Teacube Evaluation Kit

Teacube

What is Teacube?

Teacube is built on the T-Engine/VR5701 Development Kit, a standard T-Engine development kit sold by Personal Media. The CPU in the development kit is the VR5701A, developed by NEC Electronics based on the MIPS architecture. When operated at 400MHz, it delivers high processing performance of 800MIPS.

Typical power consumption when running at 266MHz is a mere 6.5W. This is a small fraction of the power used when an ordinary PC is operated along with peripheral devices. Teacube was originally designed and developed as an embedded computer for control use. As such, it even has an RS-232C interface, which has become a rarity in PCs these days but can be useful in applications where signals are to be watched.

By using compact flash for storage in place of a hard disk, it can be made more durable against faults or vibration. The compact size, moreover, offers more freedom in designing the end product, such as a kiosk terminal.

Photos

Brochure

Brochure
Teacube/VR5701 pdficon[134KB]

Contact

Personal Media Corporation
Koizumi Bldg. 1-29-1 Nishigotanda,
Shinagawa-ku, Tokyo, 141-0031 Japan
E-mail: te-sales@personal-media.co.jp
http://www.personal-media.co.jp/(Japanese)
Tel:+81-3-5759-8305
Fax:+81-3-5759-8306
  • TRON is an abbreviation of "The Real-time Operating System Nucleus".
  • eTRON is an abbreviation of "Entity TRON".
  • TRON, eTRON, T-Engine, T-Monitor, and T-Kernel are specified terms for computers, and are not product names.
  • All product names are trademarks or registered trademarks of their respective owners.
  • Due to continued product upgrade or enhancement, the information in this document is subject to change without notice.
  • T-Engine is an open, royalty-free specification, and not a commercial product.
